Qualitest Presents Advanced Bend Testing Equipment

Presenting Qualitest's range of advanced bend testing equipment, designed to perform a variety of tasks to meet your unique requirement.

Our state-of-the-art product offerings include Universal Testing Machines, Electronic Tensile Testers, Cold Bend Testing Machines, Bending Drains, and more.

Resonant Testing System for Dynamic Bending Applications: Originally designed to precrack specimens for fracture mechanics, the current versions offer much more possibilities due to a modular concept. The kinematic conditions allow a pure bending moment between the gripping heads. An electromagnetic driven resonator, built as a rotary oscillator, creates an appropriate bending moment. Independent to the dynamic drive a static moment is possible to be applied to the specimen via a torsion rod. Learn more

Bending Drain: With the Bending Drain you measure the shrinkage and bending of building materials. Also you may simulate with a built in electrical heating a real world floor heating.

High precision measurement are guaranteed, by two static abutments and a massive u-shaped steel baseplate. A neoprene foil between the form work and the material avoids friction and blocking of material, also when expanding materials are used. The form work is static independent from the mortar beam which is supported by two well defined points.

The Bending Drain has an Intra- / Internet connection and an integrated data logger. No special PC is required during the measurement. The instrument is fully controlled by your network browser software, like the Internet Explorer or similar software. All data are stored inside on non volatile memory for weeks or months. By one mouse click you can load the data directly into your Excel worksheet over a network. You may also transfer you data with a removable Compact Flash card.

You may integrate several Bending Drains into your network, but each of it is working indepently. Two high resolution LVDTs with a stroke of 5mm and a resolution of 0.3µm are delivering high reliable results. Learn more

Static Constant Loading Tester for Thermoplastic Manhole: QT-SCL Static Constant Loading Tester is mainly used to determine the resistance to the axial static constant load of plastic manhole. A constant force is steadily loaded on the axial direction of the manhole for the specified time, when the test is finished, observing the sample appearance (deformation, collapse, crack or crazing), determine the deformation in axial direction and calculate the deformation ratio of manhole. The machine is also suitable for ring stiffness test, flattening test, ring softness test of thermoplastic pipes.

BS EN 13598-1:2003 Plastics piping systems for non-pressure underground drainage and sewerage. Unplasticized poly (vinyl chloride) (PVC-U), polypropylene (PP) and polyethylene (PE). Specifications for ancillary fittings including shallow inspection chambers. It gives definitions and requirements for ancillary fittings of PVC-U, PP, and PE that can be used in non-pressure underground drainage and sewerage systems either outside the building structure or buried in ground within the building structure. Learn more

Cold Bend Testing Machine: The Cold Bend Testing Machine - QualiBend series are used for bending of metallic materials such as metal rods, planks and steel screw threads. The machines operate with a hydraulic loading system to adjust the distance of the cold-bending press roll to drive the rod in both directions making the cold bending press roll forward and back. Learn more

Electronic Tensile Tester: The electronic tensile testing equipment can be used to perform different type of tests like traction, stripping, sealing, tear, compression, bending, and cutting strength of plastic film, composite film, plastic tapes, soft packaging material, rubber sheets, paper, non-woven fabrics and other packaging materials, widely used in industries related to production of plastic films, packaging, pharmaceuticals, food, inspection agency, research institutes etc. to study properties of materials and finished products. Learn more

High & Low Temperature Universal Testing Machine: QT-UTM-HLT High and Low Temperature UTM Environmental System enables the testing of material and components under a variety of real world conditions. Cooperating with environmental chamber, XWW series machines can realize variety of tests at low or high temperature.

ASTM D638 Standard Test Method for Tensile Properties of Plastics. This test method covers the determination of the tensile properties of unreinforced and reinforced plastics in the form of standard dumbbell-shaped test specimens when tested under defined conditions of pre-treatment, temperature, humidity, and testing machine speed. Learn more

Hydraulic Universal Testing Machines: Rigid 4-column load frame construction providing superior axial and lateral stiffness and minimum maintenance, low reaction at specimen failure. Chrome plated columns for easy cleaning and longer life.

Extra-length screws and columns, with an adjustable lower crosshead, to increase the available test space for longer test specimens. Double acting crossbeam quickly accommodates specimens of varying lengths. In the case of the additional length of columns, the maximum testing space is adjustable to meet extra length specimens.

Fully open front hydraulic wedge grips make it easy to insert and remove specimens for increased productivity and operator safety.  Interchangeable design allows a limited number of jaw faces to accommodate a large range of specimen sizes. Fully open front wedge clamps for easier loading and allowing rapid loading and unloading of specimens. Including grip control system mounted directly at the machine Tooling for tension, compression, bend/flex, shear, and other tests available. With digital displacement transducer for the best positioning and measuring accuracy. Learn more

Universal Testing Machine: The Universal Testing Machine is loaded with technical features, ergonomic design and is produced with the highest quality as a benchmark. This instrument is suitable to be used in production lines, where the operator has to be fast and efficient, and accurately control the test, Testing lab environments, where using the advanced software, the users can analyze the test data, have full control on processing, filing, and test management.

A Universal Testing Machine (UTM) is used to test both the tensile and compressive strength of materials. Universal Testing Machines are named as such because they can perform many different varieties of tests on an equally diverse range of materials, components, and structures. Most UTM models are modular and can be adapted to fit the customer’s needs.

Universal Testing Machines can accommodate many kinds of materials, ranging from hard samples, such as metals and concrete, to flexible samples, such as rubber and textiles. This diversity makes the Universal Testing Machine equally applicable to virtually any manufacturing industry. Learn more

Explore our range of Environmental Testing Equipment here. We also deliver custom testing machinery based on your unique requirements.

Qualitest, with its trusted supplier network, is well aware of the various testing requirements that may arise in different industries. Besides efficient logistics and a high level of standards, we guarantee the best prices as well. Our products are built to last and various government agencies, educational institutions, and private businesses have benefitted from our advanced state-of-the-art testing products.
