Automatic Vision Measuring Machine (VMM) – QualiVMM™ AV 300 Series

Automatic Vision Measuring Machine (VMM) – QualiVMM™ AV 300 Series Applications

• Electronics and connector components
  • Measures hole patterns, edge profiles, pitch features, and positional relationships on small-to-medium parts. Saved programs help keep results consistent across operators and shifts when inspection volume is high.
• Medical devices and precision parts
  • Supports dimensional verification for housings, machined features, molded details, and assembled subcomponents. Stationary-part measurement helps when parts are lightweight, delicate, or prone to movement during inspection.
• Glass, LCD, and flat workpieces
  • Handles 2D outline and feature location tasks for flat components. A laser or probe option adds practical height checks for steps, thickness points, and surface variation based on the measurement plan.
• Aerospace and precision machining
  • Measures complex prismatic features, radii, angles, and GD&T-related characteristics through programmed routines. Automated cycles help keep inspection repeatable for recurring part families and documentation workflows.
• Batch inspection for production QC
  • Fits operations that measure many similar parts daily. After first-time programming, motion and calculations run automatically to improve throughput and reduce rework from inconsistent measurement practices.

Standards

• ISO 10360-7 (imaging probing systems)
  • Defines acceptance and reverification tests for Cartesian CMMs equipped with imaging probing systems operating in discrete-point mode, aligning well with vision-based coordinate measurement use cases.
• ISO 14978 (GPS measuring equipment requirements)
  • Establishes general requirements, calibration concepts, and metrological characteristics used across GPS measuring equipment standards, useful for consistent specification language and calibration context.
• ASME B89 family (dimensional metrology standards)
  • A widely recognized U.S. standards family for dimensional metrology practice and performance evaluation context, often referenced across coordinate measurement disciplines.
