| Color Measurement |
| Color Geometry |
45° illumination; -15°, 15°, 25°, 45°, 75°, 110° aspecular viewing |
| Measuring Area |
23 mm diameter |
| Spectral Range Colorimetric |
400 - 700 nm, 10 nm resolution |
| Measurement Range |
0 to 600 % reflectance |
| Repeatability Color |
0.01 ΔE* (10 consecutive measurements on white) |
| Reproducibility Color |
Grey BCRA II tiles: avg. ΔE* < 0.10 Chromatic BCRA II tiles: avg. ΔE* < 0.25 |
| Color Scales |
ΔE*; ΔE CMC; ΔE 94; ΔE 2000; ΔE 99; ΔE DIN6175-2019 and customer specific scales |
| Color Indices |
Flop, Int-Em |
| Illuminants |
A; C; D50; D65; F2; F7; F11; F12; CIE 015:2018 LED illuminants |
| Observer |
2°; 10° |
| General |
| Measuring time |
< 4 seconds |
| Software |
with software |
| Memory |
1000 standards / samples |
| Display |
2.7 in. TFT color LCD display |
| Languages |
English French German Italian Japanese Spanish Chinese Russian |
| Weight |
2.9 lb |
| Operating temperature |
10 - 42 °C |
| Operating temperature |
50 - 110 °F |
| Relative humidity |
up to 85%, 35° C (95° F); non-condensing |
| Dimensions: L x W x H |
21.8 x 8.1 x 14.7 cm |
| 8.6 x 3.2 x 5.8 in |
