Electric Spin Coater QualiSC-50A

Electric Spin Coater QualiSC™ 50A
Request A Quote
Parent Product
Spin Coaters – Precision Thin Film Coating Solutions
View PDF

Electric Spin Coater QualiSC™ 50A

Electric Spin Coater QualiSC™ 50A delivers precise rotary speed control for rapid thin-film formation using liquid or sol-gel coatings on substrates. Its aluminum frame ensures smooth and stable operation even at high speeds.

Product Usage
Designed for applying liquid and sol-gel coatings onto substrates.

Electric Spin Coater QualiSC-50A

Electric Spin Coater QualiSC™ 50A Technical Specifications

ParameterSpecification
Rotary Disk Diameter100mm
Adjustable Digital Display Rate500-8000 RPM
Coating ProcedureA two-step coating procedure can be set up, and the rotational speed stability is (+1%) to make the coating more uniform.
SPD1 speed: 500-8000 RPM effective
T1 time: 1-60S effective.
SPD2 speed: 500-8000 RPM effective.
T2 time: 1-60S effective
VoltageAC220/110V 50/60Hz
Power150W

Standard Package

Size400 × 300 × 200 mm
Weight20kg
