Gloss Meter Quali-TRI-Gloss-I
Gloss Meter Quali-TRI-Gloss-I

Gloss Meter Quali-TRI-Gloss-I
Parent Product
Gloss Meter – QualiGloss Series
Gloss Meter

The Quali-TRI-Gloss-I Tri-angle Gloss Meter adheres to international standard ISO 2813. It's equipped with auto-calibration and top-tier QC software, meeting strict first-grade standards. Widely used across industries like paint, ink, coatings, wood products, and more, it serves for gloss measurement and data transmission.

Gloss Meter



EASY TO USE

Gloss Meter



The Quali-TRI-Gloss-I Tri-angle High Precision Gloss Meter is extensively employed in various industries, including paint, ink, stoving varnish, coatings, wood products, marble, granite, vitrified polished tiles, pottery, brick, porcelain, plastics, paper, hardware, and more. It is utilized for both gloss measurement and the transmission of gloss data.

Gloss Meter



Quali-TRI-Gloss-I Features

  • An elegant design that combines aesthetics and ergonomics.
  • Equipped with an auto-calibration function.Gloss Meter
  • Meets the rigorous first-grade requirements.
  • Offers extensive storage for saving over 35,000 data sets.
  • Features an optional auto-power-off setting within 30 to 120 seconds.
  • Complies with ASTM D523, ISO 2813 standards.
  • Comes with PC software for generating quality reports and additional extended features.
  • Offers multiple working modes and a variety of functions to meet the diverse requirements of most customers.

Quali-TRI-Gloss-I Technical Specification

ModelQuali-TRI-Gloss-I Tri-angle Gloss Meter
Measuring Angle20° / 60° / 85°
Measuring Area (inches)

20°:0.35x0.39

60°:0.35x0.59

85°:0.2x1.5


Measuring range

20°:0~2000GU

60°:0~1000GU

85°:0~160GU


Division Value0.1GU
Measuring ModesBasic Mode; Statistic mode; Continuous mode; QC mode
Measuring Time0.5s
Repeatability0~100GU:±0.2GU
100~1000GU:±0.2%GU
AccurateConform with first grade requirements of gloss meter
Auto Power-off TimeWithin 30s-120s
Long-time CalibrationAutomatically check and made the calibration
LanguageEnglish
Storage350000(Basic mode & Statistics mode: 15000; Continuous mode: 10000 QC mode: 10000)
Display2.3 inches black and white screen
Size6.30x2.05x3.31 inches
WeightAbout 0.66 lbs
Power Supply1pc dry-cell battery(can measure 10000 times) or use USB charge
InterfaceUSB & Bluetooth 2.1 version
PC SoftwareQC software for quality report and more extended functions
Operation Temperature Range0-40°C(32-104°F)
Storage Temperature Range-20-50°C(-4-122°F)
Humidity Range<85% RH, without condensation
Standard AccessoriesUser manual, calibration plate, USB cable, user manual, QC software (Download official website)
Optional AccessoriesMiniature printer
NotificationThe technical parameter is only for reference
