Magnetic Brinell and Rockwell Hardness Tester - QualiMag-RB

Magnetic Brinell and Rockwell Hardness Tester - QualiMag-RB
Parent Product
QualiMag-Series Magnetic Type Portable Hardness Testers

QualiMag- RB portable Brinell & Rockwell hardness testers are designed based on the QualiMag-R Rockwell hardness tester and follow the test methods of Brinell and Rockwell hardness test and function as both Brinell and Rockwell hardness testers.

  • The magnetic type hardness testers are recommended to test huge or medium-size parts not available for magnetic type.
  • Brinell hardness tester is used for testing raw materials, rough castings and forgings or semi-finished product without heat treatment.
  • Rockwell hardness tester is used for product or semi-finished products after final heat treatment.

QualiMag- RB portable Brinell & Rockwell hardness testers are designed based on the QualiMag-R Rockwell hardness tester and follow the test methods of Brinell and Rockwell hardness test and function as both Brinell and Rockwell hardness testers.

  • Used for testing the castings, forgings, steels and nonferrous metal and work pieces made of all kinds of metal materials under kinds of heat treatment.
  • Capable of testing finished and semi-finished metal work pieces of various dimensions and shapes by using different anvils.
  • Traceable standard hardness block. Indenter (uncertified) inspected with standard Rockwell hardness tester.
  • Testing principle and accuracy is in accordance with the relevant international standard ISO6508, 6506 and American standard ASTM E110.

Rockwell Initial Test Force

10Kg

Rockwell Total Test Force

60Kg, 100Kg, 150Kg

Brinell test force

62.5kg, 125kg, 187.5kg

Rockwell Indenter

120° Diamond cone (uncertified), Ф1.588mm carbide ball

Brinell test ball

Ф2.5mm carbide ball

Indicator Error

Comply with ISO and ASTM

Repeatability Error

Comply with ISO and ASTM

Test resolution

Rockwell 0.5 HR

Brinell 0.005mm (Indentation Diameter)

Testing Range

Rockwell hardness HRC, HRB, HRA

Application Range

Rockwell for products or semi-finished products of Common metals, including steel, copper, aluminum, Carburized layer, hard alloy, etc. Brinell for castings, Forgings, steel raw materials, non-ferrous metal



Standard Assembly

  • 1 Tester

  • 4 V Adaptors

  • 1 120° Diamond Penetrator

  • 4 Adaptor Screws

  • 1 Steel Ball Penetrator Φ1.588mm

  • 1 Seat Iron

  • 1 Steel Ball Penetrator Φ2.5mm

  • 1 Magnifier

  • 1 Rockwell Hardness Block HRB

  • 1 Reading microscope 40x

  • 2 Rockwell Hardness Block HRC

  • 1 Carrying Case

  • 1 Brinell Hardness Block(HB2.5/187.5)

  • 1 Manu



  • Iron Seat

Optional Accessories

  • 120° Diamond cone enlarged with extra 5 mm length
  • Set of extension adaptor ( 10mm, 15mm, 20mm, 25mm,30mm) ; works with other QualiMag models
  • Carbide indenters (uncertified) (2.5 mm, 1.588 mm)
  • Rockwell hardness block
  • Brinell harness block ( HB2.5/187.5)
  • 40x reading microscope
