Probe Ultrasonicator – QualiUltra™ Probe Series

Probe Ultrasonicator – QualiUltra™ Probe Series
Parent Product
Probe Ultrasonicator
Standards
IEC 61010-1
IEC 61326-1
ISO 11201
ISO 20427

Probe Ultrasonicator – QualiUltra™ Probe Series

Probe Ultrasonicator systems in the QualiUltra™ Probe Series use high-intensity ultrasonic cavitation to break down, disperse, and homogenize liquid samples with repeatable control. The platform supports adjustable power and time settings, helping labs tune energy delivery to match fragile biomaterials, tough tissues, or hard-to-disperse particles.

QualiUltra™ Probe instruments are built for R&D and QC workflows that need fast processing, consistent emulsions, and reliable particle size reduction. Typical use cases include cell and tissue disruption, dispersion, emulsification, and sample prep for downstream analysis.

Probe Ultrasonicator – QualiUltra™ Probe Series Applications

  • Cell and tissue lysis (animal, plant, microbial)
    • Probe cavitation ruptures cell membranes and tissue structures to release proteins, enzymes, DNA/RNA, and intracellular components.
  • Bacteria and virus disruption
    • High-frequency mechanical shear helps break microbial structures for extraction, characterization, or inactivation studies.
  • Emulsification
    • Produces stable emulsions for formulations, method development, and process screening where droplet size uniformity matters.
  • Nanomaterial and pigment dispersion
    • Helps deagglomerate powders and reduce particle clusters for more uniform suspensions, supporting consistent measurements and formulations.
  • Particle size reduction and homogenization
    • Supports fast breakdown and uniform mixing of heterogeneous samples, including viscous liquids and multi-phase blends.
  • Soil, rock, and environmental sample prep
    • Improves homogenization for structural and physical characterization work, especially when samples contain mixed phases.
  • Biopharma dispersion and extraction
    • Supports dispersion of pharmaceutical substances and research-scale extraction workflows that benefit from controlled energy input.
Probe Ultrasonicator – QualiUltra™ Probe Series

Standards

  • IEC 61010-1 – Safety requirements for electrical equipment used in measurement, control, and laboratory environments.
  • IEC 61326-1 – EMC requirements (immunity and emissions) for measurement, control, and laboratory equipment.
  • ISO 20427:2023 – Describes ultrasonic dispersion procedures using a probe-type sonicator for particulate dispersion workflows.
  • ISO 11201 – Method for determining noise emission sound pressure levels at operator workstations, useful when validating sound-reduction enclosures.

Probe Ultrasonicator – QualiUltra™ Probe Series Key features

  • High-intensity cavitation for fast processing
    • Delivers strong shear forces to support disruption, dispersion, and homogenization across common lab sample types.
  • Wide operating control for repeatable methods
    • Adjustable power and programmable timing help standardize protocols across operators and shifts.
  • Probe-tip flexibility for different viscosities and volumes
    • Multiple titanium probe diameters support micro-volume work through larger batch processing.
  • Temperature protection to reduce sample risk
    • Built-in temperature monitoring and alarms help prevent overheating during longer runs.
  • Duty-cycle control for pulse or continuous operation
    • Pulse settings help manage heat buildup while maintaining effective cavitation.
  • Operator-focused safeguards and alarms
    • Time, temperature, and overload alarms support safer day-to-day operation.
  • Sound-reduction enclosure options
    • Select configurations include a soundproof box to reduce perceived noise during operation.
  • Method storage for routine workflows
    • Preset/program storage supports repeatable QC-style operation across common recipes.

Probe Ultrasonicator – QualiUltra™ Probe Series Technical specifications

ModelPowerFrequencyDisplayStandard probe (Ø)Optional probe tips (Ø)Sample volume rangeDuty cycleTemperature alarm
QualiUltra™ Probe 12001200 W (1–100% adjustable)19.5–20.5 kHz—20 mm15, 25 mm50–1000 mL0.1–99.9%0–99.9°C
QualiUltra™ Probe 10001000 W (20–100 W adjustable)20–25 kHz—6 mm2, 3, 10, 15 mm100 μL–60 mL0.1–99.9%0–99.9°C
QualiUltra™ Probe 900900 W (1–100%)20–25 kHz7-inch TFT touch screen6 mm2, 3, 10, 12, 15 mm100–500 mL0–99.9%0–99.9°C
QualiUltra™ Probe 650A650 W (1–100% adjustable)20–25 kHz7-inch touch screen6 mm2, 3, 10 mm100 μL–50 mL0.1–99.9%0–99.9°C
QualiUltra™ Probe 650B650 W (1–100%)20–25 kHz7-inch TFT touch screen6 mm2, 3, 10 mm100–500 mL0–99.9%0–99.9°C
QualiUltra™ Probe 250250 W (1–100%)20–25 kHz7-inch TFT touch screen6 mm3 mm10–100 mL0–99.9%0–99.9°C
QualiUltra™ Probe 150150 W (1–100%)20–25 kHz7-inch TFT touch screen6 mm3 mm10–100 mL0–99.9%0–99.9°C
