Cleanroom Panels

Cleanroom Panels
Parent Product
Cleanrooms

Cleanroom Panels

Qualitest offers and creates a range of materials for cleanroom buildings. These solutions include rock wool cleanroom panels, cleanroom MGO and rock wool panels, gypsum rock wool cleanroom panels, aluminum honeycomb cleanroom panels, and paper honeycomb cleanroom panels. Additionally, for the biological medicine sector, they have introduced two series: Endure and HigySteel, providing more options for customers.

Cleanroom PanelsCleanroom PanelsCleanroom PanelsCleanroom PanelsCleanroom Panels
01. Rockwool Cleanroom Panel02. MGO & Rockwool Cleanroom Panel03. Gypsum % Rockwool Cleanroom Panel04. Aluminium Honeycomb Cleanroom Panel05. Paper Honeycomb Cleanroom Panel

Cleanroom Panels Technical Specifications

ItemSpecification parameters (mm)
Width980 / 1,180
LengthWall panels 100-9,000, and ceiling panels 100-3,500
Thickness50 / 75 / 100
Panel thickness0.4-0.6
Panel materialColor-coated steel plate, Aluminum alloy plate, Stainless steel plate, Ti-Zn plate
Face coatPE (polyester), PVDF (fluorocarbon), HDP (high durable polyester)
Core materialRockwool (bulk capacity: 100-120kg / m³) glass and magnesium, gypsum, paper honeycomb, aluminum honeycomb
Thickness of keel0.6-0.8
Corner0.5 (Galvanized)
Resist film60μm / 80μm
Note: Non-standard specifications can be customized according to customer requirements.



Surface Material

ItemRock wool core plateMagnesium rock wool core platePlaster rock wool core plateAluminum honeycomb core
Plate weight18/m²17-23 kg/m³-10-15 kg/m³
Core material100-120kg/m³5mm9.5mm-
Sound transmission loss25db30db30db18db
Bend1.1KN/m²1.25KN/m²1.25KN/m²1.0KN/m²
Coefficient-1.033--
Hydrophobic rate≥98%---
Fire endurance45min60min60min41min
Note: The weight of the plate is calculated by 50mm plate thickness
