Illumination/ Viewing System | Reflection: d/8(Diffused illumination, 8 degree viewing) Simultaneous measurement of SCI/SCE (ISO7724/1, CIENo.15, ASTM E1164, ASTM-D1003-07, DIN5033 Teil7,JIS Z8722ConditionC standard)
Transmittance d/0(Diffused illumination, 0 degree viewing) |
| |
| |
| |
| |
| |
| |
Reflectance Range Resolution | |
| |
| Include UV, 400nm cut, 420nm cut, 460nm cut |
| |
| Reflectance: XLAV Φ30mm, LAV 18mm,MAV Φ11mm, SAVΦ6mmTransmittance:Φ25mm
(Auto aperture size recognition) |
Transmittance Sample Size | No limit on sample width and height, thickness ≤50mm |
| XLAV Spectrum Reflectance/Transmittance: standard deviation within 0.1%
XLAV Chromaticity value: Standard deviation within ΔE*ab0.015*When a white calibration plate is measured 30 x at 5-secondintervals after white calibration |
Inter-Instrument Agreement | XLAV ΔE*ab 0.15 (BCRA Series II, Average measurement of 12tiles,at 23℃) |
| A,C,D50,D55,D65,D75,F1,F2,F3,F4,F5,F6,F7,F8,F9,F10,F11,F12CWF,U30,DLF,NBF,TL83,TL84 |
| |
| Reflectance and Transmittance graph/value, color value, color difference values, pass/fail, color simulation, color assessment, haze, liquid chromaticity values, color tendency |
| |
| L*a*b, L*C*h, Hunter Lab, Yxy, XYZ |
| WI(ASTM E313-00,ASTM E313-73,CIE,ISO2470/R457, AATCC, Hunter, Taube Berger, Stensby)
YI(ASTM D1925,ASTM E313-00,ASTM E313-73),Tint(ASTME313-00),Metamerism index milm, stain fastness, color fastness, ISO brightness, R457, A density, T density, E density, M Density, APHA/Pt-Co/Hazen, Gardner, Saybolt, ASTM color, Haze, Total Transmittance, Opacity, Color Strength |
| ΔE*ab, ΔE*CH, ΔE*uv, ΔE*cmc, ΔE*94, ΔE*00, ΔE*ab(hunter),555shade sort |
| 8 GB U Disk for data storage and transfer |
| |
| |
| 5-40℃(40-104F), relative humidity 80% (at 35℃) no condensation |
| -20-45℃(-4-113F), relative humidity 80% (at 35℃) no condensation |
| Power Adaptor, USB Cable, fixture for transmittance, U disk (PC software), Black Calibration Cavity, White and Green Calibration Tile Reflectance Test Support,30mm,18mm,11mmand 6mmapertures, reflectance sample fixture, Glass Cell 40x10mm |
| Heating Fixture for Transmittance, Vertical Support and Pneumatic ram for downward measurement, Reflectance fixture for small size sample, Reflectance Glass Cell Support, Corrosion-Resistant Protective Plate (non-removable), Sample Holder for Fiber, Film Fixture, Transmittance Fixture for Small Aperture, Trolley Case, European Standard Plug, American Standard Plug |
| |
| |
| |
| 1. Camera to view measurement area;
2. Support horizontal, vertical and downward measurement method(need optional accessories to support for downward measurement);
3. Auto humidity and temperature compensation function. |
