| Power force(DC) | 5V and 12V (50W) |
| Control signal input | Four sets of input signal for selection |
| Two set of stress sensor: | 4~20mA |
| Two force sensor: | 1.0mV/V, 1.5 mV/V, 2.0 mV/V, 3 mV/V, 4 mV/V |
| (Internal + External) Three sets of Encoder signal input |
| Input signal: upper limit, lower limit, emergency stop, goes up, go down, set aside two sets. |
| Expand D-Sub | Input signal: 4 sets, output signal: 4 sets |
| Communication Interface | TCP/IP RJ45 Connecting Cable |
| Load cell Resolution | 31 bits |
| Load cell precision | 1/100,000 |
| Encoder signal voltage | 5V |
| Encoder signal mode | Single-ended (Open Collector), Differential square wave (Line Driver) |
| Display panel | 7 inch of TFT Color touch panel |
| Language selection | English and other languages |
| Data assess | Can use USB to proceed with data access (can export test data to Excel for further data analysis) |
| Specified software is optional for data access |
| Data sampling rate | 2, 5, 10, 25, 50, 100, 400, 1200Hz |
| Interface function | Data | Display: Force, Stress, Torque, Displacement, Time |
| Graph | Display: Force, Displacement, Time, stress, strain |
| Data Analysis: Maximum force, deformation percentage at maximum force point, stress at maximum force point, percentage of elongation at maximum force point, force at break point, deformation percentage at break point, stress at break point, percentage of Elongation at specified break point, interval average load, Max. Force and so on. |
| Unit changeable (Metric system or imperial system) |
| Calibration setting | Calibrated parameter setting can be provided |
| Can be used on various capacity of load cell and no need to recalibration after replacement |
