| High stability of the spark source |
| The solid state discharges sustainable 1h |
| Discharge parameters | Frequency 500HZ
Inductance 120H
Capacitance 5F
Voltage 400V |
| Spectrophotometric system | Vacuum optical system Aschen-runge mounting
Focal length 750mm
Spectrum range 120~800nm
Distinguishability surpass 0.01nm |
| Scanning system | Cantilever XY axis linkage
Route: X axis 300mm
Y axis 300mm
Z axis 150mm
Driven approach : All-digital AC servo drive
Position detection : incremental encoder
Position repeatability : 0.1mm
Driving mode : ball screw |
| Analysis software |
| Element quantitative analysis model | Establish and modify the analysis program, Standardization and the micro-standardized elements interfere with automatic correction |
| Segregation distribution analysis model | Segregation average content output contour map of segregation in two dimensions solid map of segregation in three dimensions statistic distribution analysis in concentration range |
| Inclusion distribution analysis model | Inclusion average content output Solid molten state quantitative results output solid map of inclusion in three dimensions particle size range distribution of inclusion |
| Porosity distribution analysis model | solid map of porosity location in three dimensions porosity |
| Sample platform |
| Size (L x W) | 500mm x 245mm |
| Load bearing | 20Kg |
| Power | 220V monophase 16A 2.5KVA |
| Temperature | 10~40°C |
| Humidity | ≤70% |
