| Measurement mode | T-E | -Standard measurement: For Normal thickness measurement.
-Minimum measurement: For curved surface
-Differential measurement: Displays the difference from the actual thickness
measurement or from a user entered reference value
-Average measurement : 2-9 point selectable
-Limit measurement: Min. Max setting and alarm |
| E-E | The metal wall thickness is accurately and quickly measured in spite of surface coating |
| Scan | thickness value at 10 measurements per second while also display actual thickness (Ideal for high temp. thickness readings) | |
| Probe identify | Auto |
| Probe zero | Auto at power up and continuously during the measurement |
| Gain adjust | Auto gain adjustment
Manual gain adjustment: low, standard and high |
| Memory | 5000 groups |
| Output | USB to PC |
| Measuring Range | E-E : 3-25mm (0.118” – 1”)
T-E: 0.65-400mm (0.026” – 15.75”)
(range depends on probe-material combination) |
| Resolution | 0.01mm (0.001 inch) for thickness up to 99.99mm
0.1mm ( 0.01 inch) for thickness above99.99mm |
| Information Display | Measurement reading, Probe type, Velocity, measurement mode, measurement Symbol, Battery |
| Velocity range | 9 material velocities are stored for selection, or entre the new velocity manually (1000m/s-9999m/s) |
| Vel. measurement | Simply calibrate when a material’s velocity is unknown |
| Display | 128 x 64 graphics LCD monochrome |
| Battery Type | 2 AAA Alkaline |
| Battery life | Up to 50 Hours (without Backlight) |
| Shut off | Auto, 2Min., 5Min., or never shut off delectable |
| Work Temperature | -20℃ - 50℃ |
| Unit | mm/inch |
| Dimensions | 115mm x 64mm x 27mm |
| Weight | 220g |
