Portable Hardness Tester – Wireless E-Dynatest

Portable Hardness Tester – Wireless E-Dynatest
Parent Product
Portable Hardness Tester
Brinell Hardness Tester

Wireless E-Dynatest is a cutting-edge portable hardness tester, delivering a test load of 100 kgf (980 N) for accurate and dependable hardness measurements. Its high test load ensures consistent results, regardless of the material's surface condition. This makes it particularly suited for large, stationary pieces, as it can be operated directly on-site.

Portable Hardness Tester – Wireless E-Dynatest Overview

Portable Hardness Tester – Wireless E-Dynatest

With wireless data transfer between the test head and a 6-inch tablet, the E-Dynatest offers quick, precise, and user-friendly hardness testing. Results are displayed instantly on the tablet, and the wireless connection ensures seamless, real-time data capture and evaluation.

The Android app further enhances functionality, allowing users to store, manage, share, and print test results efficiently. Its combination of reliability, precision, and ease of use makes the E-Dynatest an excellent tool for on-site hardness testing.

Portable Hardness Tester – Wireless E-DynatestPortable Hardness Tester – Wireless E-Dynatest
Portable Hardness Tester – Wireless E-DynatestPortable Hardness Tester – Wireless E-Dynatest

Portable Hardness Tester – Wireless E-Dynatest Advantages

  • On-Site Measurement: Designed for pieces of any size, enabling convenient hardness testing wherever needed.
  • Fully Adjustable: Allows adjustments in all directions, reducing handling and cutting costs.
  • High Test Load (100 kgf): Combines the portability of a handheld tool with the performance of a bench-top hardness tester.
  • Effortless Operation: Measures with a single manual press, ensuring fast and straightforward testing.
  • Certified Precision: Backed by ACCREDIA certification (ILAC MRA - Mutual Recognition Arrangements), providing a competitive edge in certification-focused markets.

Portable Hardness Tester – Wireless E-Dynatest Technical Specifications

Voltage100 - 240 Volt
Loads100 kgf (980 N)
Norms and certificationsDIN 50157 ASTM E-18 indirect method on certified test block ISO 6506 indirect method on certified test block ISO 6507 indirect method on certified test block ISO 6508 indirect method on certified test block ACCREDIA CERTIFICATE on request
Minimum measurable diameter25 mm standard 12 mm with special penetrator shroud
Selectable functionsScales, tolerances, calibration, test load, stats, language, sequence, files, materials, partial average, clock, auto off timer, add notes, barcode scanner, geo-localization
Output interfacesWifi, Bluetooth, micro USB, micro SD slot
ReadingTablet display touch-screen 6"
LanguagesEnglish and others
Load application methodManual
WeightMechanical unit 2050g Electronic unit 360g
Preload3,45 kgf (33.8 N)
AccuracyHRC 0,3 HB < 1%
Working principleRockwell
Standard scalesHRC (10-70) - 1HB30 (160-700) - 2HB30 (100-500)
