| Color Measurement |
| Color Geometry | 45° illumination; -15°, 15°, 25°, 45°, 75°, 110° aspecular viewing |
| Measuring Area | 23 mm diameter |
| Spectral Range Colorimetric | 400 - 700 nm, 10 nm resolution |
| Measurement Range | 0 to 600 % reflectance |
| Repeatability Color | 0.01 ΔE* (10 consecutive measurements on white) |
| Reproducibility Color | Grey BCRA II tiles: avg. ΔE* < 0.10 Chromatic BCRA II tiles: avg. ΔE* < 0.25 |
| Color Scales | ΔE*; ΔE CMC; ΔE 94; ΔE 2000; ΔE 99; ΔE DIN6175-2019 and customer specific scales |
| Color Indices | Flop, Int-Em |
| Illuminants | A; C; D50; D65; F2; F7; F11; F12; CIE 015:2018 LED illuminants |
| Observer | 2°; 10° |
| Effect Measurement |
| Effect Geometry | 15°, 45°, 75° and diffused illumination; perpendicular viewing with camera |
| Effect Parameters | ΔS; ΔS_a; ΔS_i; ΔG |
| Repeatability Effect | S_a / S_i: 5% or > 0.50 / G = ± 0.05 |
| Reproducibility Effect | S_a / S_i: 10% or > 1.00 / G = ± 0.15 |
| Effect Parameters Anodized Surfaces | Sparkle index ANO; Sparkle amount ANO |
| Repeatability Effect Anodized Surfaces | ± 250 or 2.5% (on anodized silver reference standard) |
| Reproducibility Effect Anodized Surfaces | ± 500 or 5.0% (on anodized silver reference standard) |
| General |
| Measuring time | < 6 seconds |
| Memory | 1000 standards / samples |
| Display | 2.7 in. TFT color LCD display |
| Languages | English French German Italian Japanese Spanish Chinese Russian |
| Power supply | Rechargeable battery pack or 4 mignon AA batteries (alkaline or rechargeable) |
| Weight | 2.9 lb |
| Operating temperature | 10 - 42 °C |
| Operating temperature | 50 - 110 °F |
| Relative humidity | up to 85%, 35° C (95° F); non-condensing |
| Dimensions: L x W x H | 21.8 x 8.1 x 14.7 cm |
| 8.6 x 3.2 x 5.8 in |
