Ferrograph Analysis Software – QualiFG™ FAS

Ferrograph Analysis Software QualiFG™ FAS is a software platform built to support image acquisition, wear-particle recognition, and analysis of ferrograms in one workflow. QualiFG™ FAS is a connected solution for labs using dual-analysis ferrographs, dual-rotary ferrographs, and thistle-tube ferrograph systems, with support for microscope-camera imaging, intelligent particle recognition, and report generation.

This Ferrograph software is designed for laboratories that want more consistent wear-debris review across operators and faster reporting from microscopy-based ferrography. This software is a deep-learning recognition model trained on large industrial used-oil image datasets, along with scalable architecture that can be customized for lab reporting workflows and data-system integration.

QualiFG™ FAS is a practical fit for oil analysis labs, reliability teams, and condition-monitoring programs that need a more standardized way to capture, classify, and document wear particles from ferrograms.

Ferrograph Analysis Software – QualiFG™ FAS Applications

  • Used-oil condition monitoring programs: QualiFG™ FAS supports routine ferrograph workflows for wear trending and early abnormal-wear detection. The software is intended to help users distinguish normal wear from abnormal wear patterns with more consistent image-based review.
  • Wear-mode identification and maintenance decisions: This Ferrograph software supports recognition of wear modes such as cutting, sliding, fatigue, oxides, and other common particle classes. That helps connect debris morphology with likely machine condition and maintenance action.
  • Standardized reporting for QC and reliability teams: QualiFG™ FAS includes reporting and data-interaction features intended to support repeatable records, internal documentation, and easier result sharing across teams.
  • Multi-instrument ferrograph laboratories: The software is positioned for labs running multiple ferrograph platforms. It can work with dual-analysis ferrographs, dual-rotary ferrographs, and thistle-tube ferrograph systems as one coordinated workflow.

Standards

  • ASTM D7690 – Microscopic characterization of wear and contaminant particles deposited on ferrograms.
  • ASTM D7684 – Terminology and description guidance for particle morphology used in microscopic particle identification workflows.

Ferrograph Analysis Software – QualiFG™ FAS  Key Features

  • Three-in-one workflow: QualiFG™ FAS combines image acquisition, wear-particle recognition, and wear analysis in one software environment. This helps reduce switching between separate tools during ferrograph review.
  • Real-time microscope image acquisition: the software supports real-time image capture through compatible high-quality microscope cameras. This instrument helps provide clear imaging and strong color reproduction for particle analysis.
  • Deep-learning wear-particle recognition: the recognition model is trained using large industrial used-oil image datasets. This supports stronger generalization and more robust particle classification across different ferrogram samples.
  • Wide recognition range: QualiFG™ FAS supports wear-particle recognition from 0 to 1200 μm, which covers a broad size range used in routine ferrography and condition monitoring.
  • Twelve particle categories: the software supports 12 particle-recognition categories. Examples include normal wear particles, fatigue wear particles, cutting wear particles, severe sliding wear particles, spherical particles, copper particles, and oxide particles.
  • Reporting and data interaction tools: built-in reporting functions and convenient data interaction, helping users standardize outputs and share results more easily across lab teams.
  • Expandable and customizable architecture: QualiFG™ FAS is described as highly expandable and customizable. The software can be personalized for customer-specific needs and integrated more deeply into a laboratory information ecosystem.

Theory and Method

A Ferrograph analysis workflow begins after a ferrogram is prepared and placed under a microscope. QualiFG™ FAS first captures ferrogram images through a supported microscope camera, then applies an intelligent recognition model to classify wear particles, and finally organizes the results into an analysis and reporting layer for review and export.

The recognition engine is described as a deep-learning model trained on tens of thousands of wear-particle images from industrial lubricating-oil samples. This helps the software classify particles more consistently across real-world sample variations.

The result is a more structured image-analysis workflow for ferrography, where capture, recognition, and reporting are handled as one connected process instead of separate manual steps.

Ferrograph Analysis Software – QualiFG™ FAS Technical Specification

ParameterQualiFG™ FAS
Product TypeFerrograph Analysis Software
Primary WorkflowImage acquisition, wear-particle recognition, wear analysis
Compatible Ferrograph PlatformsDual-analysis ferrograph, dual-rotary ferrograph, thistle-tube ferrograph
Referenced StandardsASTM D7690, ASTM D7684
Design ReferenceSH/T 0573
Recommended Computer10th Gen Intel Core i5-10500, 8 GB RAM or higher
Example CameraE3ISPM2000KPA
Compatible Transmission LineE301195 UL AWM Style 2725
Microscope Calibration Ruler1 DIV = 0.01 mm
Wear-Particle Recognition Range0–1200 μm
Acquisition TypeReal-time acquisition
Image Resolution5480 × 3648 / 2736 × 1824
Recognition Categories12 types
