RDE-AES Rotating Disc Electrode Atomic Emission Spectrometer - QualiRDE™ AES Oil Emission Spectrometer

QualiRDE™ AES Emission Spectrometer is as a proven means of precisely determining elemental composition of wear metals, pollutants and additives in lubricating oil, hydraulic oil, heavy fuels, coolant and electrolyte. It is used as both aquality control tool and machine health monitor.

Oil Emission Spectrometer, also known as the rotating disc Electrode Atomic emission spectrometer(RDE-AES), is a standard analytical instrument for oil element detection recognized in the global market. It is specially used to accurately quantify the composition of trace elements in various industrial oils and liquids.

Oil Emission Spectrometer provides simultaneous multi-element analysis in tens of seconds without using gases and cooling water. It is an effective tool for preventive maintenance of equipment.

Applications

Industrial Oil Monitoring
- Monitor the wear condition of equipment and the pollution and aging condition of lubricating oil
Quality Control of Lubricants, Fuels and Electrolytes
- Process preparation and monitoring of derivative or pollutant concentration in fuel oil
Cooling System Monitoring
- Monitor the element concentration in the cooling system antifreeze
Industrial Water Monitoring
- Measuring power plant cooling water and turbine wash water provides unique system condition insights and ensure compliant disposal or reuse

Electric Power

Gearbox, bearing, Analysis of copper and iron content in insulating oil

Petrochemical Industry

Equipment asset management, Product quality control Cooling water discharge detection Electrolyte and electrolysis process allocation

Mining/Engineering

Engine, hydraulic, compressor systems, Bearing monitoring, fuel element monitoring

Ships

Engine set. Generating set Hydraulic system, Cranes, etc.

Wear warning seawater pollution monitoring.

Third Party Laboratory

Oil sample testing

Aviation

Turbine/turbofan engine, Hydraulic landing gear system, Wear monitoring and warning

Schools/Institutes

Teaching Research

Locomotive Railway

Gearbox, The transmission system, Power systems, etc. Wear monitoring and warning, Oil product testing

Conforming

ASTMD6595 Standard test method for determination of wear metals and contaminants in used lubricating oils or used hydraulic fluids by rotating disc electrode atomic emission spectrometry
ASTMD6728 Standard test method for determination of contaminants in gas turbine and diesel engine fuel by RDE-AES
NB/SH/T0865-2013 Determination of wear metals and contaminants in used lubricating oils RDE-AES——Petrochemistry
SN/T1652-2005 Method for determination of contaminants in Import and export gas turbine and diesel engine fuel RDE-AES-—CIQ
HB20094.1-2012 Determination of wear metals in aviation working fluid Part1:RDE-AES——Aerospace
DL/T1550-2016 Determination of metallic copper and iron content in mineral insulating oils RDE-AES——Power Industry

RDE-AES Rotating Disc Electrode Atomic Emission Spectrometer - QualiRDE™ AES Oil Emission Spectrometer Characteristics

Fast and Easy to Operate
- No sample preparation required without the sample dilution or preheating required by other technologies
- No gases and cooling water required
- Tens of seconds analysis time
- Minimal training/background required to operate No highly skilled or trained users are required
Stable and Reliable Structure
- Classical Pashen-Rungel optical path structure
- High precision multi-CMOS acquisition system
- Full spectrum measurement while ensuring good resolution and accuracy
- Overall structural light chamber and seismic system design to ensure stability
Human Safety Protection Design
- Humanized excitation chamber design, more convenient sample replacement.
- Excitation chamber door safety interlock, electromagnetic shield design, to protect the safety of users.
Intelligent Oil Analysis and Diagnosis Platform
- Integrating oil data trend tracking analysis and oil condition automatic diagnosis function;
- Multi-peak separation computing ability, a variety of digital filtering algorithm modules and adaptive background function;
- Real-time calibration, interference correction, element identification and measurement, trend analysis and diagnosis ,historical tracing;
- Analysis software platform specially tailored for oil detection.

RDE-AES Rotating Disc Electrode Atomic Emission Spectrometer - QualiRDE™ AES Oil Emission Spectrometer Technical Specification

Application
Sample Type	Lubricating oil, hydraulic oil, fuel oil, grease, antifreeze, cooling water, electrolyte, etc.
Analytical Element	Al, Ba, B, Ca, Cr, Cu, Fe, Pb, Mg, Mn, Mo, Ni, K, Na, Si, Ag, Sn, Ti, V, Zn, etc. (extensible)
Optical System
Optical Structure	Pashen-Rungel
Spectral Region	201nm-810nm
Focal Length	400mm
Detector	Highly sensitive CMOS Array
Temperature Control	Thermally stabilized; 37°C ± 0.1°C (adjustable)
Working Parameter
Operating Temperature	-10°C~40°C
Storage Temperature	-40°C~65°C
Operating Humidity	0-95% RH, condensation free
Injection Volume	≤2ml
Injection Mode	Rotating disc electrode
Power Source
Voltage Input	220V/50Hz (110V is also available)
Power Consumption	≤500W
Output Type	AC Arc
Mechanical Specifications
Dimensions (mm³)	500(W) × 720(H) × 730(D)
Weight	About 82kg
Consumable
Top Electrode	Spectral pure graphite rod electrode
Bottom Electrode	Spectral pure graphite disc electrode
Sample Cup	High temperature oil cup
Consumable
Standard Oil	0#, 10#, 50#, 100#, ...
Standard Solution	1000ppm, ...
