Impact Testing Equipment & Accessories for Metals

Product Categories

Metal Testing Equipment

Application

Impact Tester - Impact Testing Machine

Standards

Impact Testing Equipment & Accessories for Metals

Impact toughness is a critical mechanical property for metals used in pipelines, pressure vessels, structural steelwork, and safety-critical components. Qualitest's Impact Testing Equipment & Accessories for Metals offers a fully integrated solution — from high-capacity Charpy and Izod pendulum machines to drop weight tear testers (DWTT), specimen notch preparation systems, and temperature conditioning baths.

Whether you are performing routine quality control to ASTM E23 or ISO 148, conducting nil-ductility transition temperature (NDT) testing per ASTM E208, or evaluating large-scale DWTT specimens for pipeline acceptance testing to API 5L, Qualitest provides the instrumentation, accessories, and reference specimens needed to achieve accurate, reproducible results.

All instruments are supported by Qualitest's global application engineering team and backed by comprehensive calibration, verification specimen, and after-sales service programs.

Full Product Range

#	Type	Product Name	Description / Key Function	Standards
01	Main Equipment	Charpy Impact Tester for Metals	High-capacity pendulum Charpy and Izod impact tester with up to 750J capacity. Measures absorbed energy on metallic specimens with precision digital readout.	ASTM E23 \| ISO 148-1/-2/-3 \| ASTM A370
02	Specimen Prep	Charpy Impact Specimen Notch Broaching Machine	Precision notch broaching machine producing V-notch, U-notch, and keyhole geometries in Charpy and Izod specimens to exact ASTM and ISO dimensional tolerances.	ASTM E23 \| ISO 148 \| EN 10045
03	Main Equipment	Drop Weight Tear Tester (DWTT)	Large-scale instrumented drop weight tear tester for evaluating ductile-to-brittle transition of pipeline steels. Measures shear area percentage and absorbed energy on full-thickness specimens.	API 5L \| ASTM E436 \| ISO 3183
04	Specimen Prep	Notch Pressing Machine (QualiDWTT-NPM)	Dedicated machine for producing press-notched DWTT specimens per API 5L. Delivers consistent notch geometry for accurate fracture appearance evaluation in pipeline steel qualification.	API 5L \| ASTM E436
05	Conditioning	Low Temperature Bath for Charpy Impact Testing	Precision low-temperature conditioning bath for soaking Charpy specimens to controlled sub-ambient temperatures prior to impact testing, achieving stable thermal equilibrium from ambient to cryogenic ranges.	ASTM E23, ISO 148-1
06	Main Equipment	Charpy Impact Testers for Metals	Range of semi-automatic and fully automatic Charpy impact testing systems with digital readout, automatic specimen insertion, safety guards, and PC-based data acquisition for high-throughput testing.	ASTM E23 \| ISO 148 \| EN 10045
07	Main Equipment	Drop Weight Tester — Nil Ductility Temperature (NDT)	Determines the nil ductility transition temperature (NDT) of ferritic steels via break/no-break determinations on welded bead specimens at controlled temperatures for pressure vessel steel qualification.	ASTM E208 \| ASME BPVC
08	Reference	Certified Charpy V-Notch Impact Test Specimens	Certified reference specimens with traceable absorbed energy values at defined test temperatures. Used for machine verification, indirect verification programs, and inter-laboratory comparisons.	ASTM E23 Annex \| ISO 148-2 \| ILAC
09	Conditioning	Charpy Specimen Low Temperature Chamber (QualiCHLT)	Compact cryogenic specimen conditioning chamber operating to −196°C (LN₂ or refrigerant). Enables rapid specimen transfer within the ASTM E23 and ISO 148 maximum 5-second transfer time requirement.	ASTM E23 \| ISO 148-1 \| API 5L
10	Conditioning	Low Temperature Cooling Chamber for DWTT Specimens	Purpose-built large-format cooling chamber for DWTT specimens. Maintains precise sub-zero temperatures for uniform conditioning prior to drop weight tear testing of pipeline steel specimens.	API 5L \| ASTM E436 \| ISO 3183
11	Verification	Charpy Impact Specimen Notch Projector	High-magnification optical projector for verifying notch geometry of Charpy and Izod specimens. Projects magnified specimen notch profile against standard templates to confirm ASTM E23 and ISO 148 dimensional conformance.	ASTM E23 \| ISO 148 \| EN 10045

Why Choose Qualitest for Impact Testing?

Complete Integrated System

From specimen preparation and conditioning to impact testing and notch verification — one supplier, fully compatible equipment, one support contact.

Standards Traceability

Designed to ASTM E23, ISO 148, ASTM E208, ASTM E436, and API 5L. Calibration traceable to national metrological standards (NIST, PTB, NPL).

Full Cryogenic Capability

Dedicated conditioning baths and chambers cover ambient to −196°C with liquid nitrogen, meeting the strictest pipeline and pressure vessel qualification requirements.

Certified Reference Specimens

Qualitest certified Charpy V-notch reference specimens support machine verification, indirect verification programs, and laboratory accreditation requirements.

Global Service & Support

Worldwide network of application engineers and service technicians ensures rapid on-site support, preventive maintenance, and calibration services globally.

Industry-Specific Expertise

Decades of experience in oil & gas, pipeline, structural steel, power generation, and heavy manufacturing — delivering application knowledge beyond the instrument.
