Thermal Camera Analyzers
Stand-mounted and benchtop thermal camera analyzers for circuit board repair, materials testing, and IC-level failure analysis.
Thermal camera analyzers convert infrared radiation into a visible image, revealing a hot spot on a circuit board or material sample. A multimeter alone cannot locate this kind of fault. The QualiTCA™ analyzer line spans four models, from a foldable one-click leakage detector to a 640×512 research-grade instrument. Resolution and analysis depth scale through the lineup, so buyers can match the tool to the bench.
Entry-level models suit circuit board repair technicians who need fast leakage and short-circuit location. Precision and research-grade models add a macro lens, power meter integration, and continuous monitoring for IC failure analysis and materials research. Every analyzer connects to a PC or Android device and ships with dedicated analysis software. Adjustable emissivity and radiometric video recording are standard across the higher-tier models.
Applications
QualiTCA™ thermal camera analyzers are built for electronics repair benches and materials research labs, not general field inspection. Every model in the line locates a thermal fault on a powered circuit board or sample without disassembly.
- Circuit Board Leakage and Short-Circuit Detection: locates a failing component using the highest-temperature points on a powered board
- IC and Component Failure Analysis: pinpoints an overheating chip or bond wire down to micron-scale detail on the higher-resolution models
- Materials Thermal Conductivity and Heat Dissipation Testing: tracks how heat moves through a conductive or insulating material sample
- Heating Element and Heating Wire Characterization: quantifies heating rate and temperature at different voltage and current levels
- E-Cigarette Atomizer Temperature Analysis: tracks atomizer heating rate and temperature during testing
- Product Quality Control and Aging Testing: compares a known-good sample against a test sample, with long-duration monitoring on the QualiTCA™™ 64
Thermal Camera Analyzer Range
The QualiTCA™ lineup moves from a simple foldable leakage detector through benchtop, precision, and research-grade models. Resolution and analysis features are the two specs to compare first.
| Model | IR Resolution | Measurement Range | Description |
|---|
| QualiTCA™ ™ 25A | 256×192 | -15°C to 600°C | Foldable, stand-mounted analyzer built for one-click leakage and short-circuit location on a powered circuit board, with 3D thermal field analysis and a magnification lens for close inspection. |
| QualiTCA™ ™ 25B | 256×192 | -10°C to 550°C | Adds materials thermal analysis to the QualiTCA™™ 25A's circuit board diagnostics, with a multi-axial bracket, adjustable emissivity, and double board joining for a larger working area. |
| QualiTCA™ ™ 38 | 384×288 | -20°C to 550°C | Precision analyzer with a quick-change macro lens down to 25 microns and power meter integration, built for IC failure analysis and fine material inspection. |
| QualiTCA™ ™ 64 | 640×512 | -20°C to 550°C | The highest-resolution model in the line, adding 24-hour continuous monitoring for long-duration reliability and aging tests. |
How to Choose the Right Thermal Camera Analyzer
- For simple PCB leakage and short-circuit detection: choose the QualiTCA™™ 25A for a foldable, one-click diagnostic tool.
- For circuit board repair plus broader materials analysis: choose the QualiTCA™™ 25B for adjustable emissivity and double board joining.
- For IC-level precision and power meter correlation: choose the QualiTCA™™ 38 for micron-scale macro lens inspection.
- For the highest resolution and long-duration testing: choose the QualiTCA™™ 64 for 640×512 detail and 24-hour continuous monitoring.
Why Choose Qualitest for Your Thermal Camera Analyzer
Qualitest North America supplies testing and measurement equipment to laboratories, quality teams, and manufacturers, backed by responsive technical support and calibration service. The Thermal Camera Analyzer range is built for reliable, standards-driven results, so you can source confidently from a single partner. Our team helps you match the right configuration to your samples, applicable standards, and throughput, then supports you through installation and beyond.
Request a Quote
Tell us whether you need quick PCB leakage detection, broader materials analysis, or IC-level precision with power meter integration, and we will recommend the right QualiTCA™ model. Contact the Qualitest team for pricing and lead times.
